Description
Features
- Integrated on/off switch and variable speed control knob are conveniently located
- Precision-flattened reinforced steel conveyor bed
- Precision-machined and dynamically balanced extruded aluminum drum is designed to dissipate heat and protect the work surface from heat-damage
- Separate feed and drum motors provide independent control, optimizing the performance of the sander
- Stand features a 20″ x 37″ footprint to increase stability and has a storage shelf and pre-drilled holes for casters
- The relative depth scale on the handwheel allows the user to reset and measure the depth for every project
What’s in The Box
- (1) JWDS-1632OSC DRUM SANDER W STAND
- Owner’s Manual
Warranty
- 5 Year Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
Specifications
| SKU | JT9-723525 |
|---|---|
| Brand | Jet |
| Conveyor Speed (FPM) | 0 to 10 |
| Drum Bearing Diameter (In.) | 1 |
| Drum Diameter (In.) | 5 |
| Drum Length (In.) | 16 |
| Drum Speed (RPM) | 1725 |
| Dust Port Outside Diameter (In.) | 4 |
| Maximum Board Thickness (In.) | 3 |
| Maximum Board Width (In.) | 16 |
| Minimum Board Length (In.) | 2-3/8 |
| Minimum Board Thickness (In.) | 1/32 |
| Model Number | JWDS-1632OSC |
| Motor Amps | 14 |
| Motor Power (HP) | 1-1/2 |
| Prop 65 | Cancer and Reproductive Harm |
| Recommended Circuit Size (Amps.) | 20 |
| Style (Type) | Drum Sander |
| Warranty | 5 Year |
| Weight (Lbs.) | 191 |
| Gross Weight | 227.0 |
| Net Weight | 227.0 |
