Description
Features
- For added safety, the motor and electrics follow strict guidelines and electrical requirements to be certified by CSA Group
- Dual voltage electrics (115/230V) with overload and low voltage protection
- Heavy-Duty transmission utilizes hardened and ground gears operating in an oil bath
- Fully adjustable hydraulic downfeed system
- Carbide blade guides feature parallel double-row ball bearing support
- Longer blade wheel base reduces blade fatigue and increases blade life
- Heavy-duty, rigid steel and cast iron construction of the head and base provides full blade support, eliminating vibration and deflection
- Conveniently located control panel and easily accessible coolant system
- Easy-to-use belt drive tensioner does not require tools for blade speed changes or belt replacement
- Quick-positioning vise with fully adjustable jaws, swivels to 45°
- Coolant system
- Adjustable material stop
- 1″ Bi-Metal blade
What’s in The Box
- JET J-7015 8″ x 13″ Horizontal Bandsaw 115/230V 1PH
- Owner’s Manual
Warranty
- 2-Year Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
Specifications
| Model | 414450 |
| UPC | 662756108203 |
| Cutting Capacity (W x D) (In.) | 8 x 13 |
| Round at 90 Degrees (In.) | 9 |
| Round at 45 Degrees (In.) | 9 |
| Rectangle at 90 Degrees (In.) | 9 x 13 |
| Rectangle at 45 Degrees (In.) | 9 x 8 |
| Square at 90 Degrees (In.) | 8-1/2 |
| Vise Swivels (Deg.) | 45° |
| Blade Speeds (SFPM) | 82, 132, 170, 235 |
| Blade Wheel Diameter (In.) | 11-5/8 |
| Blade Length (In.) | 114-1/2 |
| Blade Size (In.) | 1 x .035 x 114-1/2 |
| Bed Height (In.) | 27-1/2 |
| Motor (HP) | 1-1/2 HP, 115/230V, 1Ph |
| Weight (Lbs.) | 551 |
| Overall Dimensions (L x W x H) (In.) | 62-1/2 x 23 x 48 |
