Description
Features
- Perfect for homeowners, gardeners, boat owners, and more – The WX10 is lightweight, compact, and easy to use.
- Easy starting Honda mini 4-stroke commercial engine – The durable Honda GX series commercial grade engine is easy starting and provides ample power for the toughest conditions.
- Lightweight – At only 13 lbs., the WX10 is easily portable.
- Advanced pump design for superior durability and performance – The WX10 has been completely redesigned by Honda R & D for quality and durability. Improvements to the impeller, case, engine frame bed, and other pump components add to the WX10’s impressive durability and performance.
- Garden hose adaptor, suction hose, clamps, and strainer included – Comes with everything you need to get started. Just hook up a garden hose, and you’re ready to pump.
- 3 position discharge port – The WX10’s discharge port can be changed to 3 different positions, providing added flexibility.
- Standard transport handle – The WX10 is easy to carry wherever you need it.
- 32 gal./min capacity – Uses regular gasoline – no mixing of oil and gas!
- Easier priming – The priming port is thoughtfully designed to make priming easier and reduce drips and spills.
What’s in The Box
- 1″ Lightweight General Purpose Pump
- Owner’s Manual
Warranty
- 1 Year Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
Specifications
| SKU | WX10TN |
| Brand | Honda |
| Engine | GX25 |
| Displacement | 25cc |
| Bore and Stroke | 1.4″ x 1.0″ |
| Compression Ratio | 8.0:1 |
| Oil Alert | N/A |
| Pump Type | General purpose Centrifugal Self-priming |
| Volute | Aluminum |
| Impeller | Aluminum |
| Mechanical Seal (Pump case / impeller) | Carbon/Ceramic |
| Priming Time | 80 sec. at 16.4 ft. |
| Drive System | Direct |
| Discharge Capacity | 32 gal./min. |
| Suction Port Diameter | 1.0″ NPT |
| Discharge Port Diameter | 1.0″ NPT |
| Total Head Lift | 121 ft. |
| Suction Head Lift | 26 ft. |
| Maximum Pressure | 52 psi |
| Solids Handling | N/A |
| Dimensions (L x W x H) | 13.4″ x 8.7″ x 11.6″ |
| Dry Weight | 13 lbs. |
| Fuel Capacity | 0.56 qt |
| Run Time @ Max Discharge | 0.9 hr |
| Strainer Part # | 78325-YB0-711 |
| Residential Warranty | 2 years |
| Commercial Warranty | 1 year |
